DISASSEMBLY OF BASIC ENGINE
5-6
2.
Disassembling and in
specting flywheel
Disassembling and inspecting flywheel
Disassembling sequence
1
Flywheel
3
Oil seal case, oi
l seal
2
Flywheel housi
ng

Rep
l
ace
:
Gasket
Crack,
damage,
abnorma
l
knock
ho
l
e
Wea
r
,
damage,
ag
i
ng
of
o
il
sea
l


Damage
to
threaded
port
i
on
Streak,
stepped
wear
and
crack
of
worn
surface
and
damage
and
abnorma
l
wear
of
r
i
ng
gear
59
61
