63
This referential program is made by a master I/O structure based on the structural figure of the
transmission signal structure on page 62. Data link start of the CC-Link shows the start with the
buffer memory parameters.
To start with the EEPROM parameters, enter the parameters in the EEPROM in advance and then
read out the parameters. Refer to FX2N-32CCL model CC-Link interface User's manual or Master
unit manual.
M907
X21
Numeric data
transmission
command
Numeric data receipt
completed
K50 D300
MOV
MOV
H8 D301
MOV K54 D302
H4 D303
MOV
MOV
K56 D304
MOV K500 D305
K57 D306
MOV
MOV
H2 D307
MOV K0 D308
MOV K0 D309
K1 D300
MOV
MOV
K250 D301
MOV K2 D302
K20 D303
MOV
MOV
K15 D304
MOV K25 D305
K16 D306
MOV
MOV
K50 D307
MOV K20 D308
MOV K120 D309
PLS M0
M807
X20
M907M0
H1E0 D300 K10TO H0
SET M807
RST M807
END
RET
M907X22
M907
Memory switch setting
Multi reels control
MC5 setting
OUT remote
Tension full scale
500
Tension full scale decimal point
×1
Tension setting
250
Stall setting
20％
Manual setting
25％
Start timer setting
5.0 s
Gain 1 setting
120％
Transmission of numeric data
to LE-40MTB-E
Writing data device
Starting data device
transmission
Confirming data device receipt
→ Resetting “transmission completed ”
Numeric data
transmission
command
Numeric data
transmission
command
Numeric data receipt
completed
Numeric data
transmission completed
Numeric data
transmission
completed
( No setting )
( No setting )
