5 - 14
5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
Table5.9 Power supply module specifications
Item
Performance Specifications
A1S61PN A1S62PN A1S63P
Base loading position Power supply module loading slot
Applicable base unit
QA1S6 B
Input power supply
100 to 240VAC
(85 to 264VAC)
24VDC
(15.6 to 31.2VDC)
Input frequency
50/60Hz 5%
----
Input voltage
distortion factor
Within 5% ( Section 5.2.3)
---
Max. input apparent
power
105VA ----
Max. input power ---- 41W
Inrush current
20A within 8ms
*5
81A within 1ms
Rated
output
current
5VDC 5A 3A 5A
24VDC ---- 0.6A ----
Overcurrent
protection
*1
5VDC 5.5A or more 3.3A or more 5.5A or more
24VDC ---- 0.66A or more ----
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC ----
Efficiency 65% or more
Allowable momentary
power failure time
*3
Within 20ms
Within 10ms
(at 24VDC input)
Dielectric withstand
voltage
Across inputs/LG and outputs/FG
2830VAC rms/3 cycles (2000 m (6562 ft.))
500VAC across primary and
5VDC
Insulation resistance
Across inputs and outputs (LG and FG separated), across inputs
and LG/FG, across outputs and FG/LG 10M or more by
insulation resistance tester
5M or more by insulation
resistance tester
Noise durability
• By noise simulator of 1500Vp-p noise voltage, 1 s noise width
and 25 to 60Hz noise frequency
• Noise voltage IEC61000-4-4, 2kV
By noise simulator of 500Vp-p
noise voltage, 1 s noise width
and 25 to 60Hz noise frequency
Operation indication LED indication (Normal: ON (green), Error: OFF)
Fuse Built-in (Unchangeable by user)
Contact output
section
No
Terminal screw size M3.5 screw
Applicable wire size
0.75 to 2mm
2
Applicable solderless
terminal
RAV1.25 to 3.5, RAV2 to 3.5
Applicable tightening
torque
0.66 to 0.89N•m
External
dimensions
H 130mm (5.12inch)
W 55mm (2.17inch)
D 93.6mm (3.69inch)
Weight 0.60kg 0.50kg
+10%
-15%
+30%
-35%
To Next Page
