5
POWER SUPPLY MODULE
5.2 Specifications
5.2.1 Power supply module specifications
5 - 15
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
GENERAL
SPECIFICATIONS
4
HARDWARE
SPECIFICATIONS OF
THE CPU MODULE
5
POWER SUPPLY
MODULE
6
BASE UNIT AND
EXTENSION CABLE
7
MEMORY CARD AND
BATTERY
8
CPU MODULE START-
UP PROCEDURES
Table5.10 Power supply module specifications
Item
Specifications
A61P A61PN A62P A63P
Slot position Power supply module loading slot
Applicable base unit
QA6 B
Input power supply
100VAC to 120VAC
(85VAC to 132VAC)
24VDC
(15.6VDC to 31.2VDC)
200VAC to 240VAC
(170VAC to 264VAC)
Input frequency
50/60Hz 5%
–
Input voltage
distortion
Within 5% ( Section 5.2.3)
–
Max. input apparent
power
160VA 155VA 65W
Inrush current
20A, 8ms or less
*5
100A, 1ms or less
Rated
output
current
5VDC 8A 5A 8A
24VDC – 0.8A –
Overcurrent
protection
*1
5VDC 8.8A or more 5.5A or more 8.5A or more
24VDC – 1.2A or more –
Overvoltage
protection
*2
5VDC 5.5 to 6.5V 5.5 to 6.5V 5.5 to 6.5V
24VDC –
Efficiency 65% or more
Dielectric withstand
voltage
Between AC external terminals and ground, 1500V AC, 1 minute
Between DC external terminals and ground, 500V AC, 1 minute
Noise durability
By noise simulator of 1500Vp-p noise voltage, noise width 1 s, and 25 to
60Hz noise frequency
By noise simulator of
500Vp-p noise voltage,
noise width 1 s, and 25
to 60Hz noise
frequency
Insulation resistance
Between AC external terminals and ground, 5M or higher by 500VDC insulation resistance tester
Power indicator LED indication of power supply
Terminal screw size
M4 0.7 6
Applicable wire size
0.75 to 2mm
2
Applicable solderless
terminal
R1.25-4, R2-4
RAV1.25, RAV2-4
Applicable tightening
torque
78 to 118 Ncm
External
dimensions
H 250mm(9.84inch)
W 55mm(2.17inch)
D 121mm(4.76inch)
Weight 0.98 kg 0.75 kg 0.94 kg 0.8 kg
Allowable momentary
power failure time
*3
20ms or less 1ms or less
+10%
-15%
+30%
-35%
+10%
-15%
To Next Page
