5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
Table5.11 Power supply module specifications
Item
Performance specifications
A61PEU A62PEU
Slot position Power supply module loading slot
Applicable base unit
QA6 B
Input power supply 100 to 120/200 to 240VAC +10%/-15%
Input frequency
50/60Hz 5%
Input voltage distortion
Within 5% ( Section 5.2.3)
Max. input apparent power 130VA 155VA
Inrush current
20A, 8ms or less
*5
Rated output
current
5VDC 8A 5A
24VDC – 0.8A
Overcurrent
protection
*1
5VDC 8.8A or more 5.5A or more
24VDC – 1.2A or more
Overvoltage
protection
*2
5VDC 5.5 to 6.5V –
24VDC –
Efficiency 65% or more
Dielectric
withstand voltage
Between
primary side
and FG
2830V AC rms/3 cycles (altitude 2000m (6562ft.))
Noise durability
By noise simulator of noise voltage IEC801-4, 2kV, 1500Vp-p,
noise width 1 s, and noise frequency 25 to 60Hz
Power indicator LED indication of power supply
Terminal screw size
M4 0.7 6
Applicable wire size
0.75 to 2mm
2
Applicable solderless terminal RAV1.25-4, RAV2-4
Applicable tightening torque 98 to 137N cm
External
dimensions
H 250mm(9.84inch)
W 55mm(2.17inch)
D 121mm(4.76inch)
Weight 0.8 kg 0.9 kg
Allowable momentary power
failure time
*3
20ms or less
