Mitsubishi Q01CPU User Manual

12
TROUBLESHOOTING
12.3 Error Code List
12.3.3 Error code list (1000 to 1999)
12 - 57
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
*4 Function version is B or later.
*5 Function version is A.
*6 The module whose first 5 digits of serial No. is 04101 or later.
*7 The module whose first 5 digits of serial No. is 07032 or later.
*8 The module whose first 5 digits of serial No. is 08032 or later.
*9 The module whose first 5 digits of serial No. is 09012 or later.
*10 The Universal model QCPU except the Q02UCPU.
*11 The Q13UDHCPU and Q26UDHCPU
*12 This applies to the QnUDE(H)CPU.
*13 The module whose first 5 digits of serial No. is 10042 or later.
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
1000
Runaway or failure of CPU module or
failure of main CPU
• Malfunctioning due to noise or other
reason
• Hardware fault
• Take noise reduction measures.
• Reset the CPU module and RUN it
again.If the same error is displayed
again, this suggests a CPU module
hardware fault.(Contact your local
Mitsubishi representative.)
1001 Q00J/Q00/Q01
Qn(H)
QnPH
QnPRH
QnU
1002
1003
1004
1005
Q00J/Q00/Q01
Qn(H)
QnPH
QnPRH
QnU
Rem
1006
Q00J/Q00/Q01
Qn(H)
QnPH
QnPRH
QnU
1007 Qn(H)
QnPH
QnPRH
1008
1009
• A failure is detected on the power
supply module, CPU module, main
base unit, extension base unit or
extension cable.
• When using the redundant base unit,
the redundant power supply module
failure in both systems and/or the
redundant base unit failure are
detected.
Reset the CPU module and RUN it
again.If the same error is detected
again, it is considered that the power
supply module, CPU module, main
base unit, extension base unit or
extension cable is faulty.
(Contact your local Mitsubishi
representative.)
Q00J/Q00/
Q01
*4
Qn(H)
*6
QnPH
QnPRH
QnU
