12 - 230
12.3 Error Code List
12.3.11 Error codes returned to request source during communication with CPU module
12
TROUBLESHOOTING
Table12.12 Error code
Error code
(Hexadecimal)
Error item Error details Corrective action
413A
H
File-related
errors
File-related
errors
The specified file has exceeded the already
existing file size.
Execute again after checking the size of the specified
file.
413B
H
The same file was accessed simultaneously
from different peripheral devices.
Execute again after a while.
413C
H
The specified file is write-inhibited. Execute again after changing the file condition.
413D
H
The specified file capacity cannot be secured.
Execute again after increasing the capacity of the
specified drive (memory).
413E
H
Operation is disabled for the specified drive
(memory).
Execute again after changing the target drive (memory).
413F
H
The file is inhibited from write to the standard
RAM.
Execute again after changing the specified drive
(memory).
414A
H
Intelligent
function
module
specification
error
Operation was executed for the intelligent
function module of the non-control group in the
multiple CPU system.
Execute the operation again from the control CPU of the
target module.
414C
H
The I/O address of the specified CPU module
is wrong.
Execute again after checking the I/O address of the
specified CPU module.
4150
H
File-related
errors
An attempt was made to format the drive
protected by the system.
Do not format the target drive (memory) as it cannot be
formatted.
4151
H
An attempt was made to delete the file
protected by the system.
Do not delete the target file as it cannot be deleted.
4160
H
Online
registration
error
The registered number of forced inputs/
outputs exceeded the maximum value.
Deregister the unused forced inputs/outputs.
4165
H
The multiple-block online change system file
does not exist.
Execute again after securing the area that enables
multiple-block online change at the time of
programmable controller memory format.
4166
H
Cannot be executed since file batch online
change is being made by the same starting
source.
Since the file batch online change executed previously
remains abnormally terminated for some reason
(example: communication disturbance during execution),
file batch online change is disabled.
Forcibly perform new file batch online change.
4167
H
Cannot be executed since file batch online
change is being made from the other starting
source.
Since the file batch online change executed previously
from the other communication route remains abnormally
terminated for some reason (example: communication
disturbance during execution), file batch online change is
disabled.
If file batch online change is not being executed by the
other peripheral device, forcibly perform new file batch
online change.
4168
H
The registered number of device test with
executing condition exceeds 32.
Deregister the device test with executing condition in
CPU module, or decrease the number of registering
device test with executing condition at one time.
4169
H
The device test with executing condition has
never been registered.
Deregister the device test with executing condition after
checking the registered number of device test with
executing condition in CPU module.
416A
H
The specified executing condition does not
exist.
(Device test with executing condition)
Check whether the specified executing conditions
(program, step No. operation timing, device name) in
deregistering are registered.
416B
H
The specified program is SFC program.
(Device test with executing condition)
Check the specifing program name in de/registering the
device test with executing condition.
To Next Page
