APPENDICES
Appendix 1 External Dimensions
Appendix 1.4 Extension base unit
App - 15
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTINGAPPENDICES INDEX
Appendix 1.4 Extension base unit
(1) Q52B
(2) Q55B
(3) Q63B
Unit : mm (inch)
Diagram App.26 Q52B
Unit : mm (inch)
Diagram App.27 Q55B
Unit : mm (inch)
Diagram App.28 Q63B
7.5
(0.30)
44.1
(1.74)
98 (3.86)
80 0.3
7
(0.28)
15.5
(0.16)
106 (4.17)
83.5 0.3
(3.29 0.01)
I/O0 I/O1
OUTIN
4-mounting screws (M4×14)
(3.15 0.01)
I/O2I/O1I/O0 I/O3 I/O4
7.5
(0.30)
44.1
(1.74)
98 (3.86)
80 0.37
(0.28)
15.5
(0.61)
189 (7.44)
167 0.3 (6.57 0.01)
OUTIN
4-mounting screws (M4×14)
(3.15 0.01)
I/O0
FG
I/O2I/O1
7.5
(0.30)
44.1
(1.74)
98 (3.86)
7
(0.28)
15.5
(0.61)
189 (7.44)
POWER
5V
SG
OUTIN
4-mounting screws (M4×14)
80 0.3
(3.15 0.01)
167 0.3 (6.57 0.01)
