2.1 System Configuration
2.1.1 System Configuration for Single CPU System
2
SYSTEM CONFIGURATION
Note4Note5
Cautions
• Do not use extension cables exceeding an overall extension length of 13.2m
(43.31ft.).
• When using an extension cable, keep it away from the main circuit (high
voltage and heavy current) line.
• Set up the number of extension stages so that the number is not duplicated
with another.
• If both the Q5 B and Q6 RB extension base units are used together, the
order of connection is not restricted. Refer to Section 6.1.4 and check
whether the module is applicable or not.
• The QA1S6 B, QA6 B, QA6ADP+A5 B/A6 B or Q6 B cannot be
connected as an extension base unit.
• Connect the extension cable from OUT of the extension cable connector of
the base unit to IN of the extension base unit on the next stage.
• If the number of installed modules has exceeded the maximum number of
mountable I/O modules, an error "SP.UNIT LAY ERR." (error code: 2124)
occurs.
• When the redundant base unit is used, bus connection of GOT is not
available.
Table2.3 Restrictions on system configuration and applicable base units, extension
cables and power supply modules
Maximum number of
extension stages of
extension base units
7 extension stages
Note2.4 Note2.5
Maximum number of
mounted I/O modules
64 modules
Note2.4 Note2.5
Applicable redundant
base unit model
Q38RB
Applicable extension
base unit model
Models requiring no power supply module Q52B, Q55B
Models requiring a redundant power supply
module
Q68RB
Extension cable QC05B, QC06B, QC12B, QC30B, QC50B, QC100B
Redundant power
supply module
Q63RP, Q64RP
Note4
Note5
Basic
Note2.4
Universal
UD
Note2.5
When Q00CPU or Q01CPU is used:
Maximum number of extension stages of the extension base unit : 4 stages
Maximum number of mountable I/O modules : 24 modules
Basic
Note2.4
When the Q02UCPU is used:
Maximum number of extension stages of the extension base unit : 4 stages
Maximum number of mountable I/O modules : 36 modules : 36odules
Universal
UD
Note2.5
