SYSTEM CONFIGURATION
2.1 System Configuration
2.1.2 System Configuration for Bus connection of GOT
2 - 30
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT AND EXTENSION CABLE
7
MEMORY CARD AND BATTERY
8
CPU MODULE START- UP PROCEDURES
Note8Note9
Table2.6 Restrictions on the system configuration and applicable base units, extension
cables and power supply modules
Maximum number of
extension stages for bus
connection of GOT
When using Q00JCPU : 2
When using Q00CPU, Q01CPU or Q02UCPU : 4
When using High Performance model QCPU, Process CPU,
Q03UDCPU, Q04UDHCPU, Q06UDHCPU, Q13UDHCPU,
Q26UDHCPU, Q03UDECPU, Q04UDEHCPU, Q06UDEHCPU,
Q13UDEHCPU or Q26UDEHCPU, : 7
The final stage is occupied
by GOT.
Maximum number of
mountable I/O modules
When using Q00JCPU : 16 No. of connected GOTs
When using Q00CPU or Q01CPU : 24 No. of connected GOTs
When using Q02UCPU : 36 No. of connected GOTs
When using High Performance model QCPU, Process CPU,
Q03UDCPU, Q04UDHCPU, Q06UDHCPU,
Q13UDHCPU, Q26UDHCPU, Q03UDECPU,
Q04UDEHCPU, Q06UDEHCPU,
Q13UDEHCPU or Q26UDEHCPU : 64 No. of connected GOTs
Applicable main base
unit
Note2.8
Q33B, Q35B, Q38B, Q312B, Q38DB, Q312DB
Applicable extension
base unit
Models requiring no power supply
module
Q52B, Q55B
Models requiring the Q series
power supply module
Q63B, Q65B, Q68B, Q612B
Models requiring the AnS series
power supply module
Note2.9
QA1S65B, QA1S68B
Applicable extension
cable
QC05B, QC06B, QC12B, QC30B, QC50B, QC100B
Q series power supply
module
Note2.8
Q61P-A1, Q61P-A2, Q61P, Q62P, Q63P, Q64P, Q64PN
AnS series power supply
module
Note2.9
A1S61PN, A1S62PN, A1S63P
Note8
Note9
Basic
Note2.8
High
Performance
Note2.9
Basic
Note2.8
High
Performance
Note2.9
Because the Q00JCPU is the CPU module with a power supply module and main base unit
incorporated, the main base unit (Q3 B) and Q series power supply module are not required.
Basic
Note2.8
Usable only when the High Performance model QCPU is used.
Note2.9
High
Performance
