c) Auto refresh settings
• PLC No.1
Auto refresh CPU specific send range(U3E0\)
No.
Point Start End Start End
1 28 M3072 M3519 — G16980 G17007
2 42 M4800 M5471 — G17008 G17049
3 118 D640 D757 — G17050 G17167
• PLC No.2
Auto refresh CPU specific send range(U3E1\)
No.
Point Start End Start End
1 46 M2000 M2735 — G15840 G15885
2 42 M4000 M4671 — G15886 G15927
3 320 D0 D319 — G15928 G16247
4 600 D800 D1399 — G16248 G16847
5 320 D8000 D8319 — G16848 G17167
d) PLC system
Only "Points occupied by empty slot" is overwrite at the sample data
diversion. The content before sample data diversion are retained
without rewriting for the other data.
Setting items Description
Low speed 100ms
1 Timer limit setting
High speed 10.00ms
RUN Not used
2 RUN-PAUSE contacts
PAUSE Not used
3 Latch data backup operation valid contact Not used
4 Remote reset Not checked
5 Output mode at STOP to RUN Check the Previous state
6 Floating point arithmetic processing —
7 Intelligent function module setting Not used
8 Module synchronization Check the Synchronize intelligent module's pulse up
9 Common pointer No. Not used
10 Points occupied by empty slot 16 points
Interrupt counter start No. —
I28 Fixed scan interval 100.0ms
I29 Fixed scan interval 40.0ms
I30 Fixed scan interval 20.0ms
11 System interrupt settings
I31 Fixed scan interval 10.0ms
12 Interrupt program / Fixed scan program setting Not check the High speed execution
13 A-PLC Not checked
14 Service processing setting Scan time rate 10%
15 CPU module change setting Not used
