Mitsubishi Q170MCPU User Manual

APP - 39
A
PPENDICES
Processing time of operation instructions (continued)
Classifications Symbol Instruction Operation expression
Processing time [µs]
Q170MCPU
MULTW H800,#0,K256,M0
MULTW H800,D800,K256,M0
58.0
MULTW
Write device data to CPU
shared memory of the self
CPU
MULTW H800,U3E1\G10000,K256,M0 151.5
MULTR #0,H3E0,H800,K1
MULTR D800,H3E0,H800,K1
20.5
MULTR U3E1\G10000,H3E0,H800,K1 22.0
MULTR #0,H3E0,H800,K10
MULTR D800,H3E0,H800,K10
30.5
MULTR U3E1\G10000,H3E0,H800,K10 31.5
MULTR #0,H3E0,H800,K100
MULTR D800,H3E0,H800,K100
140.5
MULTR U3E1\G10000,H3E0,H800,K100 152.0
MULTR #0,H3E0,H800,K256
MULTR D800,H3E0,H800,K256
412.0
MULTR
Read device data from
CPU shared memory
MULTR U3E1\G10000,H3E0,H800,K256 435.0
TO H0,H0,#0,K1
TO H0,H0,D800,K1
18.5
TO H0,H0,U3E1\G10000,K1 20.5
TO H0,H0,#0,K10
TO H0,H0,D800,K10
28.0
TO H0,H0,U3E1\G10000,K10 30.5
TO H0,H0,#0,K100
TO H0,H0,D800,K100
145.5
TO H0,H0,U3E1\G10000,K100 183.0
TO H0,H0,#0,K256
TO H0,H0,D800,K256
432.0
TO
Write device data to
intelligent function module
TO H0,H0,U3E1\G10000,K256 545.0
FROM #0,H0,H0,K1
FROM D800,H0,H0,K1
20.0
FROM U3E1\G10000,H0,H0,K1 19.5
FROM #0,H0,#0,K10
FROM D800,H0,H0,K10
30.0
FROM U3E1\G10000,H0,H0,K10 33.5
FROM #0,H0,#0,K100
FROM D800,H0,H0,K100
188.0
FROM U3E1\G10000,H0,H0,K100 200.5
FROM #0,H0,H0,K256
FROM D800,H0,H0,K256
559.0
FROM
Read device data from
intelligent function module
FROM U3E1\G10000,H0,H0,K256 577.5
TIME K1
TIME #0
TIME D800
2.5
Others
TIME Time to wait
TIME U3E1\G10000 3.5
