2 - 12
2 SYSTEM CONFIGURATION
Motion controller related module(continued)
Part name Model name
(Note-1)
Description
Current
consumption
5VDC[A]
Remark
MR-J3BUS M
• Q170MCPU
MR-J3- B
• MR-J3-
B MR-J3- B
• Standard cord for inside panel
• 0.15m(0.49ft.), 0.3m(0.98ft.), 0.5m(1.64ft.), 1m(3,28ft.), 3m(9.84ft.)
——
MR-J3BUS M-A
• Q170MCPU
MR-J3- B
• MR-J3-
B MR-J3- B
• Standard cable for outside panel
• 5m(16.40ft.), 10m(32.81ft.), 20m(65.62ft.)
——
SSCNET cable
MR-J3BUS
M-B
(Note-4)
• Q170MCPU
MR-J3- B
• MR-J3-
B MR-J3- B
• Long distance cable
• 30m(98.43ft.), 40m(131.23ft.), 50m(164.04ft.)
——
(Note-1) : =Cable length (015: 0.15m(0.49ft.), 03: 0.3m(0.98ft.), 05: 0.5m(1.64ft.), 1: 1m(3.28ft.), 2: 2m(6.56ft.),
3: 3m(9.84ft.), 5: 5m(16.40ft.), 10: 10m(32.81ft.), 20: 20m(65.62ft.), 25: 25m(82.02ft.),
30: 30m(98.43ft.), 40: 40m(131.23ft.), 50:50m(164.04ft.)
(Note-2) : Be sure to use the cable for forced stop input (sold separately). The forced stop cannot be released
without using it.
Cable for forced stop input is not attached to the Motion controller. Please purchase the cable for length
according to system separately.
(Note-3) : 5VDC internal current consumption of shared equipments with PLC might be changed.
Be sure to refer to the MELSEC-Q series PLC Manuals.
(Note-4) : Please contact your nearest Mitsubishi sales representative for the cable of less than 30m(98.43ft.).
