2 SYSTEM CONFIGURATION
(2) PLC module which can be controlled by Motion CPU area
Part name Model name Description
Current consumption
5VDC[A]
(Note-1)
Remark
AC QX10 100-120VAC, 7-8mA, 16 points, Terminal block
0.05
(TYP, All points ON)
QX40 24VDC/4mA, Positive common, 16 points, Terminal block
0.05
(TYP, All points ON)
QX40-S1
High response type, 24VDC/6mA, Positive common,
16 points, Terminal block
0.06
(TYP, All points ON)
QX41 24VDC/4mA, Positive common, 32 points, Connector
0.075
(TYP, All points ON)
(Note-2)
QX41-S1
High response type, 24VDC/4mA, Positive common,
32 points, Connector
0.075
(TYP, All points ON)
(Note-2)
QX42 24VDC/4mA, Positive common, 64 points, Connector
0.09
(TYP, All points ON)
(Note-2)
QX42-S1
High response type, 24VDC/4mA, Positive common,
64 points, Connector
0.09
(TYP, All points ON)
(Note-2)
QX70
12VDC/5V, Positive common/Negative common shared,
16 points, Terminal block
0.055
(TYP, All points ON)
QX71
12VDC/5V, Positive common/Negative common shared,
32 points, Terminal block
0.07
(TYP, All points ON)
QX72
12VDC/5V, Positive common/Negative common shared,
64 points, Terminal block
0.085
(TYP, All points ON)
QX80 24VDC/4mA, Negative common, 16 points, Terminal block
0.05
(TYP, All points ON)
QX81 24VDC/4mA, Negative common, 32 points, Connector
0.075
(TYP, All points ON)
(Note-2)
Input
module
DC
QX82-S1
High response type, 24VDC/4mA, Negative common,
64 points, Connector
0.09
(TYP, All points ON)
(Note-2)
Contact output
module
QY10
240VAC/24VDC, 2A/point, 8A/common,
16 points/common, Terminal block
0.43
(TYP, All points ON)
QY40P
12V/24VDC, 0.1A/point, 1.6A/common, 16 points/common,
Terminal block
0.065
(TYP, All points ON)
QY41P
12V/24VDC, 0.1A/point, 2A/common, 32 points/common,
Connector
0.105
(TYP, All points ON)
(Note-2)
QY42P
12V/24VDC, 0.1A/point, 2A/common,
64 points(32 points/common), Connector
0.15
(TYP, All points ON)
(Note-2)
Sink
Type
QY50
12V/24VDC, 0.5A/point, 4A/common,
16 points(16 points/common), Terminal block
0.08
(TYP, All points ON)
QY80
12V/24VDC, 0.5A/point, 4A/common,
16 points(16 points/common), Terminal block
0.08
(TYP, All points ON)
Transistor
Source
Type
QY81P
12V/24VDC, 0.1A/point, 2A/common,
32 points(32 points/common), Connector
0.095
(TYP, All points ON)
(Note-2)
QY70
5/12VDC, 16mA/point, 16 points(16 points/common),
Terminal block
0.095
(TYP, All points ON)
Output
module
TTL•CMOS
(Sink)
QY71
5/12VDC, 16mA/point, 32 points(32 points/common),
Connector
0.15
(TYP, All points ON)
(Note-2)
