2 - 14
2 SYSTEM CONFIGURATION
PLC module which can be controlled by Motion CPU area(continued)
Part name Model name Description
Current consumption
5VDC[A]
(Note-1)
Remark
QH42P
24VDC Positive common: 32 points
12-24VDC/0.1A Output Sink type: 32 points, Connector,
Provided (Thermal protectors, protector against short
circuit)
0.13
(TYP, All points ON)
(Note-2)
Input/Output
composite
module
DC Input/
Transistor
output
QX48Y57
24VDC Positive common: 8 points
12-24VDC/0.5A Output Sink type: 7 points, Terminal block,
Provided (When face is broken, LED lights and signal is
output to CPU)
0.08
(TYP, All points ON)
Interrupt module QI60 24VDC/4mA, Positive common, 16 points, Terminal block
0.06
(TYP, All points ON)
Q62AD-DGH
2ch, A/D conversion,
Current input (Channel-isolated • High resolution)
0.33
Q64AD 4ch, A/D conversion, Voltage • Current input 0.63
Q64AD-GH
4ch, A/D conversion,
Voltage • Current input (Channel-isolated • High resolution)
0.89
Q68ADV 8ch, A/D conversion, Voltage input 0.64
Q68ADI 8ch, A/D conversion, Current input 0.64
Q62DA 2ch, D/A conversion, Voltage • Current output 0.33
Q62DA-FG
2ch, D/A conversion,
Voltage • Current output (Channel-isolated)
0.37
Q64DA 4ch, D/A conversion, Voltage • Current output 0.34
Q68DAV 8ch, D/A conversion, Voltage output 0.39
Analogue module
Q68DAI 8ch, D/A conversion, Current output 0.38
(Note-1) : 5VDC internal current consumption of shared equipments with PLC might be changed.
Be sure to refer to the MELSEC-Q series PLC Manuals.
(Note-2) : Connectors are not provided.
(3) PLC module which can be controlled by PLC CPU area
They are the same modules as the PLC modules which can be controlled by the
universal model QCPU "Q03UDCPU".
Refer to the MELSEC-Q series PLC Manuals.
(4) Servo amplifier
Part name Model name Description Remarks
MR-J3- B
MR-J3- B-RJ004 For linear servo motor
MR-J3- B-RJ006 For fully closed control
MR-J3- B-RJ080 For direct drive motor
MR-J3 series
servo amplifier
MR-J3W-B For 2-axis type
Battery MR-J3BAT
Back-up for the absolute
position detection
Refer to catalogue of the servo amplifier.
(5) Operating system software
Application Software package
Conveyor assembly use SV13
SW8DNC-SV13QG
Automatic machinery use SV22
SW8DNC-SV22QF
