1-6 Contents of the Option equipment and special specification
1
General configuration
Table 1-3 ： The list of controller option equipment and special specification
Item Type Specifications
Classification
Note1)
Note1) Distinction of ○ (is option) and □ (is special specification at shipping) is shown for each pair with the
controller.
Description
CR750 CR751
Simple teaching pendant R32TB Cable length 7m ○ - With 3-position enable switch IP65
R32TB-15 Cable length 15m ○ -
R33TB Cable length 7m - ○
R33TB-15 Cable length 15m - ○
Highly efficient teaching
pendant
R56TB Cable length 7m ○ -
R56TB-15 Cable length 15m ○ -
R57TB Cable length 7m - ○
R57TB-15 Cable length 15m - ○
Parallel I/O Interface 2D-TZ368
(Sink type)
DO: 32 point
DI: 32 point
Insulated type output signal
(0.1A/24V /point)
○○
The card type external input-and-output.
Interface. Install to the slot of controller.
2D-TZ378
(Source type)
DO: 32 point/
DI: 32 point
Insulated type output signal
(9mA/ 24V /point)
External I/O cable
(For Parallel I/O Interface)
2D-CBL05
5m
○○
Use to connect the external peripheral
device to the parallel input/output inter
-
face.
2D-CBL15
15m
○○
Parallel I/O Unit 2A-RZ361
(Sink type)
DO: 32 point/
DI: 32 point
Insulated type output signal
(0.1A/24V /point)
○○
The unit for expansion the external
input/output.
Electrical isolated Type
(100mA/Point)
2A-RZ371
(Source type)
DO: 32 point/
DI: 32 point
Insulated type output signal
(7mA/ 24V /point)
External I/O cable
(For Parallel I/O Unit)
2A-CBL05 5m ○ ○ Use to connect the external peripheral
device to the parallel input/output unit
2A-CBL15 15m ○ ○
CC-Link interface 2D-TZ576 Only Intelligent device station,
Local station
○○
For MELSEC PLC with CC-Link con
-
nection.
RT ToolBox2
(Personal computer Sup
-
port software)
3D-11C-WINE CD-ROM
○○
MS-Windows2000/XP/Vista/7
(With the simulation function)
RT ToolBox2 mini
(Personal computer Sup
-
port software mini)
3D-12C-WINE CD-ROM
○○
MS-Windows2000/XP
/Vista/7
Instruction Manual
5F-FE01-PE01 RV-2F-D series
○○
