3-40 Names of each part
3 Controller
<5> Machine cable connector (motor signal)
CN2: Motor signal
<6>T/B connection connector (TB) ........This is a dedicated connector for connecting the R33TB. When not using T/
B, connect the attached dummy plug.
<7>Filter cover..................................................There is an air filter and buttery inside this cover.
<8>CNUSR connector....................................The connector for input/ output connection dedicated for robot.
(CNUSR1、 CNUSR2) (a plug connector attached)
<9>Grounding terminal...................................The grounding terminal for connecting cables of option card. (M3 screw x 2
places)
<10>Power supply charge lamp (CRARGE)
The lamp is to ensure safe timing (prevent electric shocks) when removing
the cover (users are not normally required to remove the cover).
This lamp is illuminated (red) when electrical energy accumulates on the
controller’s power supply circuit board due to the robot’s servo being ON.
After turning the control power OFF and allowing a few minutes to pass,
the lamp will go out.
<11>USB connecting connector (USB)..For USB connection
<12>LAN connector (LAN)...........................For LAN connection
<13>ExtOPT connector (ExtOPT)............Connect the cable for addition axis control.
<14>RIO connector (RIO).............................Connect the extension parallel input/output unit.
<15>Option slot ................................................Install the interface optional. (Install the cover, when not using.)
(SLOT1、 SLOT2)
Use the network equipments (personal computer, USB hub, LAN hub, etc) confirmed by
manufacturer. The thing unsuitable for the FA environment (related with conformity,
temperature or noise) exists in the equipments connected to USB. When using network
equipment, measures against the noise, such as measures against EMI and
the addition of the ferrite core, may be necessary. Please fully confirm the operation by
customer. Guarantee and maintenance of the equipment on the market (usual office
automation equipment) cannot be performed.
Caution
