Mitutoyo ID-C - Page 15

3
No. 99MAH057A
1 Overview
50.8 mm stroke model
ø19.2 (0.76 in) 33.2 (1.31 in) 11 (0.43 in)
ø8
0
-0.009
ø9.52
0
-0.03
85.2 (3.35 in)
110.652
97.3
19.5
65.3
7.3
1/4 in
3.74 in
0.68 in
2.62 in
2.05 in 4.32 in
ø59 (2.32 in)
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
0.375 in
ø4.8 (0.19 in)
ID-C0550NXB
ID-C0550MNXB
ID-C0550ENXB
Unit: mm (in)
