Mitutoyo ID-C - Display Angle Adjustment

13
No. 99MAH057A
2 Preparations before Use
2.5
DisplayAngleAdjustment
The display can rotate up to 90° (A) clockwise or 240° (D) counterclockwise
from the initial position. Adjust it to an angle from which it can be easily read.
D
A
B
C
NOTICE
• Do not rotate beyond the stoppers at B and C positions. This may cause damage.
• Do not pull or push the display. This may cause damage.
