Mitutoyo ID-C - Setting Parameters; Selecting Parameter Items

37
No. 99MAH057A
5 Setting Parameters
(Short press) / (Long press)
5
Setting Parameters
5.1
Selecting Parameter Items
The parameter setting mode includes the following parameter items.
y ID-C0525NXB, ID-C0550NXB: 9 types
y ID-C0525MNXB, ID-C0525ENXB, ID-C0550MNXB, ID-C0550ENXB: 10 types
y ID-C1025NXB, ID-C1050NXB: 8 types
y ID-C1025MNXB, ID-C1025ENXB, ID-C1050MNXB, ID-C1050ENXB: 9 types
■List of parameters
Display Setting details Default setting
ModE Measurement mode selection Standard 1
unit Unit system selection
(ID-C0525MNXB, ID-C0525ENXB,
ID-C1025MNXB, ID-C1025ENXB,
ID-C0550MNXB, ID-C0550ENXB,
ID-C1050MNXB, ID-C1050ENXB)
in
dir. Counting direction selection Positive
direction
rES. Resolution selection
(ID-C0525NXB, ID-C0525MNXB,
ID-C0525ENXB, ID-C0550NXB,
ID-C0550MNXB, ID-C0550ENXB)
0.0005 mm
0.00002 in
toL. Tolerance judgment result display selection
and allowed value setting
Display OFF
CALC. Calculation function selection and calculation
coe󰀩cientsetting
Calculation OFF
A-bAr Analog bar display selection Display ON
S-SEL Switch function selection Default
F-Loc Function lock setting Lock OFF
othEr Change other functions -
CAL.ALt Calibration schedule warning selection/setting Warning OFF
outPut Digimatic output selection
(ID-C0525NXB, ID-C0525MNXB,
ID-C0525ENXB, ID-C0550NXB,
ID-C0550MNXB, ID-C0550ENXB)
DIGIMATIC d2
Auto.oF Auto OFF setting OFF
rESEt All reset -
