Mitutoyo ID-C - Names and Dimensions of Components

2
1 Overview
No. 99MAH057A
1.2
Names and Dimensions of Components
1. 2.1 Main Unit
25.4 mm stroke model
①
②
④
⑤
⑥
⑦
⑧
⑨
⑪
③
ø4.8 (0.19 in)
ID-C0525NXB
ID-C0525MNXB
ID-C0525ENXB
ø8
0
-0.009
0.375 in
ø9.52
0
-0.03
ø59 (2.32 in)
57.7 (2.27 in)
84.826
40.8
7.3
1/4 in
1.66 in
0.68 in
2.67 in
1.02 in 3.30 in
19.5
70
ø19.2 (0.76 in) 33.2 (1.31 in) 11 (0.43 in)
⑩
Unit: mm (in)
①
Cap
⑦
Stem
②
I/O connector (with cover)
⑧
Plunger
③
Display (LCD)
⑨
Contact point
④
[F1] key
⑩
Battery holder
⑤
[F2] key
⑪
Flat back
⑥
[F3] key
