Mitutoyo ID-C - Selecting Analog Bar Display

55
No. 99MAH057A
5 Setting Parameters
(Short press) / (Long press)
5.8
Selecting Analog Bar Display
The analog bar display can be turned ON/OFF. In addition, settings of the
displayed analog bar scale (±20) can be changed.
F1
F3
F1
F3
2
-1
3
-2
3
-1
1
2
-2
2
-2
F1/F3
F2
F2F2
F1
F3
F2
Go to the
next item
Go to the
next item
1 Pressthe[F2]key.
» Analog bar display can be set.
