2 Preparations before Use
No. 99MAH057A
2.3
Mounting the Lifting Lever and Lifting Knob
Lifting lever (supplied) and lifting knob (optional) can be mounted.
2.3.1 Lifting Lever
1 Fixtheplunger,usingpliersorthelikepaddedwitharag,etc.,sothatit
does not turn.
2 Insert the lifting lever into the plunger.
3 Rotatetheliftinglevertoadjusttheorientation.
