CHAPTER 1: DESCRIPTION
UNIFLOW
®
2 PULSED THERMODE CONTROL
1-2 990-228
Control Models
The standard model of the Control has a front panel with controls and a display for operator control of
the Control.
Model/Part # Type of Operation
AC Input
Voltage
Output Heating
Capability
1-292-01
Front panel. Has front panel controls and display for
local operator programming. 24 VAC valve outputs
120
2 KVA
For thermodes up to
2.3” (60 mm) long
1-292-01-01
Front panel. Has front panel controls and display for
local operator programming. 24 VAC valve outputs
240
4 KVA
For thermodes up to
4” (100 mm) long
1-292-01-02
Front panel. Has front panel controls and display for
local operator programming. 24 VDC valve outputs
240
4 KVA
For thermodes up to
4” (100 mm) long
Heads, Thermodes and Accessories
For details of solder reflow and heat seal heads, thermodes and accessories available from Unitek
Miyachi, see Technical Manual 990-230, Applying Process Control to Pulse Heated Reflow Soldering,
or contact Unitek Miyachi using the phone, e-mail, or mailing information in the Foreword of this
manual.
