3
This instruction manual is designed to help you build a straight, great flying airplane. Please read this manual
thoroughly before beginning assembly of your new Extra 300. Use the parts listing below to identify and
separate all of the parts before beginning assembly.
ÄKIT CONTENTSÃ We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you have all
of the parts required before you begin assembly and will also help you familiarize yourself with each part.
ELEVATOR CONTROL SYSTEM
TAIL WHEEL ASSEMBLY
MAIN GEAR ASSEMBLY
AIRFRAME ASSEMBLIES
AILERON CONTROL SYSTEM
MOTOR MOUNT ASSEMBLY
MISCELLANEOUS ITEMS
FUEL TANK
THROTTLE CONTROL SYSTEM
RUDDER CONTROL SYSTEM
KIT CONTENTS
q {2} Wing Halves w/Ailerons, Hinges & Torque Rods
q {1} Fuselage w/Servo Hatch
q {1} Horizontal Stabilizer w/Elevator & Hinges
q {1} Vertical Stabilizer w/Rudder & Hinges
q {1} Molded Plastic Belly Pan
q {1} Molded Plastic Belly Pan Doubler
q {1} Molded Plastic Pilot Head
q {1} Molded Fiberglass Cowling
q {1} Molded Clear Canopy
q {1} Aluminum Main Gear Bracket
q {2} 50mm Diameter Wheels
q {2} Molded Plastic Wheel Pants
q {2} 3mm x 35mm Machine Screws
q {3} 3mm x 15mm Machine Screws
q {2} 2mm x 8mm Wood Screws
q {7} 3mm Flat Washers
q {2} 3mm Nylon Spacers
q {4} 3mm Nylon Insert Nuts
q {1} Tail Wheel Bracket w/Wire
q {1} 25mm Diameter Tail Wheel
q {1} 2mm Wheel Collar
q {1} 3mm x 6mm Machine Screw
q {2} 3mm x 12mm Wood Screws
q {1} 4mm x 300mm Nylon Pushrod
q {1} 2mm x 62mm Threaded Wire w/90º Bend
q {1} 2mm x 93mm Prebent Threaded Wire
q {1} Nylon Clevis w/2mm I.D. Hole
q {1} Nylon Snap Keeper
q {1} Nylon Control Horn w/Backplate
q {2} 2mm x 15mm Machine Screws
q {1} 4mm x 200mm Nylon Pushrod
q {1} 1.5mm x 52mm Threaded Wire w/Z-Bend
q {1} 1.5mm x 45mm Threaded Wire
q {1} Nylon Clevis w/1.5mm I.D. Hole
q {1} 4mm x 300mm Nylon Pushrod
q {1} 2mm x 62mm Threaded Wire w/90º Bend
q {1} 2mm x 100mm Threaded Straight Wire
q {1} Nylon Clevis w/2mm I.D. Hole
q {1} Nylon Snap Keeper
q {1} Nylon Control Horn w/Backplate
q {2} 2mm x 15mm Machine Screws
q {2} Nylon Adjustable Control Horns
q {2} 2mm x 70mm Threaded Wire w/90º Bend
q {2} Nylon Clevis w/2mm I.D. Hole
q {2} Nylon Snap Keepers
q {2} Nylon Motor Mount Beams
q {8} 3mm x 20mm Machine Screws
q {16}3mm Flat Washers
q {8} 3mm Nylon Insert Nuts
q {1} 190cc Molded Plastic Fuel Tank
q {1} Rubber Stopper
q {1} 70mm Silicon Fuel Line
q {1} Weighted Clunk
q {1} 70mm Aluminum Tube
q {1} 40mm Aluminum Tube
q {1} 30mm Aluminum Tube
q {1} 15mm Diameter Rear Squash Plate
q {1} 20mm Diameter Front Squash Plate
q {1} 3mm x 20mm Machine Screw
q {1} Fuselage Servo Tray D-15
q {1} Dihedral Brace W-23
q {1} Wing Bolt Doubler W-25
q {3} Aileron Servo Mounting Plates W-24
q {2} Cowl Mounting Blocks D-30
q {2} 3mm x 25mm Machine Screws
q {2} 3mm Flat Washers
q {2} 3mm Blind Nuts
q {3} 3mm x 6mm Wood Screws
q {1} Molded Plastic Spinner
q {2} 2mm x 12mm Wood Screws
q {1} 3mm x 15mm Wood Screw
