7. Debug Features
Debug features are used to determine reasons for coin reject, and are output on the coin
acceptor LED by a number of red pulses (see Table 3 below).
The coin acceptor LED under normal operation should be GREEN.
The LED is situated above the 6 way DIL switch on the connector side on the acceptor (See
Figure 6).
Table 3: Debug Features
1 RED pulse Coin accepted / reject lever pressed
2 RED pulses Coin outside programmed sensor windows
3 RED pulses Coin valid, but inhibited
4 RED pulses Master Inhibit from host machine
Debug features will not be buffered and assume a single coin insertion. The insertion of several
coins would cause an overflow and no useful information.
The debug features operate in normal acceptor operation.
The LED cannot be seen if the machine door is closed.
