The following error codes are supported.
Table 15: Error Codes
Code Error
1
Reject coin
2
Inhibited coin
3
Multiple window ( ambiguous coin type )
6
Accept sensor timeout
8
2nd close coin error ( coin insertion rate too high )
14
Accept sensor blocked
15
Sorter opto blocked
17
Coin going backwards
23
Credit sensor reached too early
24
Reject coin ( repeated sequential trip )
25
Reject slug
27
Games overloaded
28
Number of coin meter pulses overloaded
254
Coin return mechanism activated ( flight deck open )
The following fault codes will be supported.
Table 16: Fault Codes
Code Fault
1
EEPROM checksum corrupted
2
Fault on inductive coils
3
Fault on credit sensor
4
Fault on piezo sensor
8
Fault on sorter exit sensors
22
Fault on thermistor
34
Temperature outside operating limits
The following status codes will be supported.
Table 17: Status Codes
Code Status
1
Coin return mechanism activated ( flight deck open )
