11. Teach and Run™ Option
The SR3 can have the option to enable Teach & Run™ on all 12 coins.
This option is selected at the time of order. The specific coin channel to be programmed is
selected using switch 1 (MSB) to switch 4 (LSB) on the 6 way DIL switch.
11.1 Programming Steps
To programme a coin / token please follow these 6 Steps:
1. Switch off the power to the SR3.
2. Set the 6 way DIL switch to the relevant coin to be programmed. (See Table 6 and
Table 7 below)
3. Switch on the power to the SR3.
4. Press the reject lever.
The LED will turn RED.
5. Start entering the coins
1
or tokens
1
you wish to teach until the LED flashes GREEN,
typically after around 10 insertions
2
.
6. Press the reject lever and the LED will turn RED then GREEN.
The coin channel is now programmed
3
.
To programme further coin channels, repeat from step 1.
Once you have finished programming return all switches to the OFF position.
The first coin inserted after Teach & Run™ may reject. Subsequent coins should accept.
Notes:
1
If a large sample of coins/tokens are used, then the coin channel sensor windows will
be more accurate and a higher acceptance of true coins/tokens should be seen. If only
a single coin/token is used, coin channel sensor windows will be programmed which
may not truly reflect the coin/token population.
2
If significantly more than 10 coins have been inserted and the LED is still not changing
to GREEN, this could be caused by three possible reasons.
a) The coins/tokens being used are actually 2 different types although they look
the same e.g. 1p old and 1p new.
b) The coins/tokens being used are poorly manufactured/minted to such an extent
that the Teach & Run™ is unable to correlate the readings taken.
c) The SR3 has a fault.
3
Even though a coin/token has been programmed make sure that the coin channel or
bank has actually been enabled (see sections 9 and 10
).
Teach & Run™ does NOT automatically enable the taught coin/token.
