HTP-1 Installation and User Guide Release 1.8.1
Speaker Position
Speaker
Notation
DTS Azimuth
Range
(degrees)
DTS Elevation
Range
(degrees)
DTS Nominal
(Azimuth,
Elevation)
Comment
Center
C
0
0
(0,0)
Left
L
-30 to -45
0
(-30,0)
Right
R
30 to 45
0
(30,0)
Left Surround
Ls
-100 to -120
0
(-110,0)
DTS 5.1 layout
Right Surround
Rs
100 - 120
0
(110,0)
DTS 5.1 layout
LFE 1
LFE1
N/A
N/A
N/A
Left Rear Surround
Lsr
-135 to -150
0
(-150,0)
Right Rear Surround
Rsr
135 to 150
0
(150,0)
Left Side Surround
Lss
-90
0
(-90,0)
DTS 7.1 Layout
Right Side Surround
Rss
90
0
(90,0)
DTS 7.1 Layout
Left Front Height
Lh
-30 to -60
20 - 45
(-45,45)
Right Front Height
Rh
30 to 60
20 - 45
(45,45)
Left Wide
Lw
-50 to -70
0
(-60,0)
Right Wide
Rw
50 to 70
0
(60,0)
Left Side Height /
Top
Lhs / Ltm
-90
20 - 45
(-90,45)
wider than Atmos, farther
front than Auro
Right Side Height /
Top
Rhs / Rtm
90
20 - 45
(90,45)
wider than Atmos, farther
front than Auro
Left Rear Height
Lhr
-110 to -150
20 - 45
(-135,45)
Right Rear Height
Rhr
110 to 150
20 - 45
(135,45)
Left Top Front
Ltf
-30 to -60
50-70
(-45,60)
Right Top Front
Rtf
30 to 60
50-70
(45,60)
Left Top Rear
Ltr
-110 to -150
50-70
(-135,60)
Right Top Rear
Rtr
110 to 150
50-70
(135,60)
Speaker Positions based on DTS recommendations, with comments.
HTP-1 User Manual Page 27 V1.8.1
