monolith HTP-1 - Valid Speaker Configurations

HTP-1 Installation and User Guide Release 1.8.1
Valid Speaker Configurations
The HTP-1 can support up to 16 output channels. There can be up to 9 main level channels, 6
upper/height channels, and up to 5 subwoofers. These can be allocated in various ways. Some of the
more complex ways are discussed in the following sections. The speaker configuration page counts the
number of channels enabled and blocks you with a message if you try to enable more than 16.
The speakers in the main and upper levels are restricted to the following configurations:
Main Level Speaker Count/Configuration
Upper Level Options*
2 Speakers: L/R Front
0 or 2 Speakers
3 Speakers: L/R Front + Center
0 or 2 Speakers
4 Speakers: L/R Front +L/R Surround
0, 2, or 4 Speakers
5 Speakers: L/R Front + Center + L/R
Surround
0, 2, 4, or 6 Speakers
6 Speakers: L/R Front + L/R Surround + L/R
Rear
0, 2, 4, or 6 Speakers
7 Speakers: L/R Front + Center + L/R
Surround + L/R Rear/Back
0, 2, 4, or 6 Speakers
8 Speakers: Not Supported
0, 2, 4, or 6 Speakers
9 Speakers: L/R Front + Center + L/R
Surround + L/R Rear + L/R Wide
0, 2, 4, or 6 Speakers
*Refer to the table below regarding upper level options.
HTP-1 User Manual Page 29 V1.8.1
