Specifications
Model
HTP-1
Part Number
38788
Video Inputs
8x HDMI®
Audio-Only Inputs
2x analog stereo RCA, 3x digital coaxial, 3x digital optical, 1x
AES/EBU, 1x ARC/eARC
Streaming Inputs
USB audio, Bluetooth®
Video Outputs
1x HDMI ARC/eARC, 1x HDMI
Audio Outputs
16-channels balanced XLR line outputs, max level 4.0vRMS.
Unbalanced stereo analog RCA mix output.
Triggers
1x trigger input, 4x trigger outputs
HDMI Version / HDCP™ Version
2.0 / 2.3
Maximum Video Resolution
4K@60Hz UHD
Audio Performance
THD+N = 106dB at 1.8Vrms, 20-20 kHz, AES17
Dynamic Range = 116dB, 4Vrms, 20 kHz BW, A-weighted
Frequency Response = 20-20 kHz, +1/-0.2 dB
Supported Audio Codecs
Dolby Atmos®, Dolby TrueHD™, Dolby Digital®, Dolby Surround®,
DTS:X®, DTS Neural:X®, DTS-HD Master Audio™, Auro-3D®,
Auro-Matic®
Crossover
Variable 4th order Linkwitz-Riley
Room Correction/Equalization
Dirac Live® (licensed with HTP-1 ownership)
Built-in Audio Correction
Bass and Treble tone controls, 16-band parametric equalizer with
independent speaker control on each band
Connectivity
Wired 10/100Mbps Ethernet, Wi-Fi®
Input Power
100 ~ 240 VAC, 50/60 Hz
Dimensions
17.1" x 5.7" x 12.0"
