Operating Manual
PulseNG Kit
Scenario #
The active scenario is shown. You can select 1 of 8 possible scenarios.
Scenario name
The name of the current scenario.
Teach count
Count Meaning
0 Teach duration can be entered
1-99 Number of teach cycles
Table 8: Teach count
Teach time
When teach count is 0, teach time can be entered in seconds.
Teaching is off when teach count and number of teach cycles is set to 0.
Limit 1-3
Setting Meaning
Enabled When disabled, no signals are shown and monitoring is switched
off.
Limit Shows the currently valid limit value.
Possible values: 0.1-150
Alarm suppr. When alarms are suppressed, alarm outputs and emergency
shut-off will not be triggered. There will only be entries into the
event log.
Window size Affects the sample rate.
Possible values: 1-255
*For peak-to-peak, the value must be at least 2.
Channel Assignment of axis, module (a (m/s²), v (mm/s)), or temperature
(°C, °F ) to the respective limit.
Limit type Choose Upper or Lower limit.
Upper limit: An alarm is triggered when the DSP limit is
NOT exceeded by the raw signals.
Lower limit: An alarm is triggered when the signals fall
below the DSP limit.
HP Filter (Hz) High pass lter
Possible settings from 0-1600
