Operating Manual
PulseNG Kit
Setting Meaning
DSP (Digital Signal Processor)
Peak to peak, Average, Area, RMS (Root Mean Square)
Delay Range of values 0-100000, in ms.
When the outputs are not set to „Latched“, you can set the length
of time after which the output will be triggered after an error
event.
Latched When activated, the outputs will be switched until the alarms are
deleted.
When deactivated, the outputs will be switched for the length of
time specied in „Delay“.
LP Filter (Hz) Low pass lter
Possible settings from 0-1600
DSP Scale For Area DSP only. Automatically set after teach operations.
Teach multiplier Figured into the raw signal during teach operations to determine
the limit value.Range of values Upper Limit: 1.1-255 Range of
values Lower Limit: 0.1-0.9
Emergency stop Determines whether exceeding the respective limit will activate
output 4 (Out4) or not.
Alarm count Number of suppressed alarms in succession.Only when the
alarm count is up, will an alarm output be triggered.
Range of values: 0-65535
Target value For Area DSP only.
Range of values: 5-80
Table 9: Limit 1-3
Load le
3 Load le Save le OK Cancel
Loads saved scenario from a local le.
Save le
3 Load le Save le OK Cancel
Saves a scenario to a local le.
