5. Setting up the device
19
Menu level Parameterisation level
Assignment (deposit) of key functions,
Default:
For operation mode, special functions can be deposited on the navigation keys
[▲] [▼], in particular this function was made for devices in housing size 48x24mm
which do not have a 4th key ([O]-key). If the min/max-memory is activated with
, all measured min/max-values are saved during operation and can be
recalled via the navigation keys. The values get lost by restart of the device. If the
threshold value correction or is choosen, the values of the threshold can
be changed during operation without disturbing the operating procedure. With
the device is set temporarily on a parameterised value. The device acknowledges
the correct taring with in the display. switches into the offset value and
can be adjusted via the navigation keys. Via the current value of the totaliser
can be displayed for approx. 7 seconds, after this the device switches back on the
parameterised display value. If is deposited, the totaliser can be set back by
pressing the navigation keys [▲] [▼], the device acknowledges this with in
the display. By allocation on the min/max-memory is deleted. At the
measuring value is shown for approx. 7 seconds, after this the device switches
back on the parameterised display value. With the brightness of the display is
adjusted. This setting is not saved and gets lost during a restart of the device. Via
selection , , , threshold values can be addressed via the navigation
keys; they can be changed digit per digit or taken over by pushing the [P]-key. The
adjustment is taken over directly, an excisting limit value monitoring and the
current measurement will not be influenced by this. If is selected, the navigation
keys are without any function in the operation mode.
