52
ROUTINE MAINTENANCE
1
2
Bottom feed wheel
Chipper housing
Anvil
3
4
Chipper drum
5
Top feed wheel
Knife pocket
Discharge chute
Figure 3.4
Feed Wheels and Chipper Drum
