ROUTINE MAINTENANCE
,
,
®
Figure 3.10
Hydraulic oil
ll/vent cap
Fuel ller cap
Fuel sight gauge
Hydraulic oil lter
Fuel tank
Hydraulic
oil tank
Sight gauge
Hydraulic Oil and Fuel Tank
Inspection cover
Valve
closed
Valve open
Hydraulic shut-off valve,
located on the fuel and
hydraulic tanks
Located on back
side of hydraulic tank
