ROUTINE MAINTENANCE
Engine
Typical Engine Conguration
Figure 3.12
Radiator screen
(radiator is housed
behind the screen)
Engine
(engine models vary)
Sheave
Engine belt
drive
Engine housing
Control panel
Note:”Panel will vary with
engine make and model
and is shown for
illustrative purposes only.”
Air lter
Engine belt drive
adjustment bolts
Right View
Clutch
Left View
Engine belt drive
adjustment bolts
Mufer
