#65060/INTL-K-10.2020 MORIA 11
IX. USE OF FOOTPEDAL
A. COMPATIBILITY FOOTPEDAL-CONSOLE
• Footpedals (#19361 and 19381) with serial number inferior to 7000 are not compatible with
EVOLUTION 3E consoles (#19380) having a serial number superior to 7000.
• EVOLUTION 3E consoles (#19380) with serial number superior to 7000 are compatible only with
footpedals (#19361, 19381, 19381C et 19381J) having a serial number superior to 7000.
Footpedal
(#19361, 19381, 19381C, 19381J)
EVOLUTION 3E console (#19380)
5000 < sn < 7000 sn > 7000
5000 < sn compatible not compatible
5000 < sn < 7000 compatible not compatible
sn > 7000 not compatible compatible
B. COMPATIBILITY FOOTPEDAL-HANDPIECE
• Footpedal #19361 can be used with M2 and One Use-Plus handpieces, as well with turbines for
ONE and CB. Footpedal #19361 can not be used with the Epi-K™ handpiece.
• Footpedal #19381 can be used with M2, One Use-Plus and Epi-K™ handpieces, as well with
turbines for ONE and CB.
C. MANUAL MODE
What to do
IMPORTANT WARNINGS
Related
Press the vacuum footswitch (C1)
once: vacuum is ON
Press again the vacuum footswitch
(C1): vacuum is OFF
The system displays the actual vacuum value in mmHg (A7).
When a suction ring is xated on the eye, the vacuum value
displayed must be less than 250 mmHg.
If the value displayed is above 250 mmHg, please refer to chapter
X.
C1
Press the forward footswitch (C2):
blade oscillation
In case vacuum is not activated, the forward footswitch does not
work.
Blade oscillation stops once forward footswitch is not pressed any
longer.
C2
Press the backward footswitch (C3):
no action
Do not press footpedal (C2) and (C3) at the same time. C3
D. AUTOMATED MODE
What to do
IMPORTANT WARNINGS
Related
Press the vacuum footswitch (C1)
once: vacuum is ON
Press again the vacuum footswitch
(C1): vacuum is OFF
The system displays the actual vacuum value in mmHg (A7).
When a suction ring is xated on the eye, the vacuum value
displayed must be less than 250 mmHg.
If the value displayed is above 250 mmHg, please refer to chapter
X.
C1
Press the forward footswitch (C2):
• blade oscillation
• forward pass of microkeratome
In case vacuum is not activated, the forward footswitch does not
work.
When the forward footswitch is not pressed any longer :
• microkeratome stops
• blade oscillation stops.
M2/One Use-Plus keratomes and turbines for ONE and CB:
footpedals #19361 and 19381 operate at only one forward speed.
Epi-K™ only (footpedal #19381): 3 forwards speeds available
when press the footpedal (slow – medium – fast):
• 1
st
step: slow forward speed, with a continuous tone
• 2
nd
step: medium forward speed, with a louder tone than with
1
st
step
• 3
rd
step: fast forward speed, with a louder tone than with 2
nd
step
Use B6 button to vary tone level.
C2
B6
Press the backward footswitch (C3):
• backward pass of
microkeratome
• no blade oscillation
Pressing the backward footswitch induces a backward pass of the
microkeratome even if:
• vacuum is OFF
• “Low Vacuum” option is ON
Do not press footpedal (C2) and (C3) at the same time.
C3
X. TROUBLE SHOOTING
A. POWER SUPPLY
Message Reason Intervention
LED (A9-A11)
ON + Audible
tone
Loss of main power supply
during surgery AND Battery
charged (>90%)
Control unit runs on battery
supply
The system runs automatically on the backup battery: check LED
A11 is OFF.
At the end of the surgery case, connect the console to the main
power supply to recharge the battery immediately: check LED A11
is ON.
LED (A10) ON
+ Audible tone
Loss of Main Power supply:
Main power supply is defective
during surgery AND Battery
discharged
Control unit runs on a
discharged battery supply
Connect the console to the main power supply to recharge the
battery immediately.
