Morris Quantum - Opener Body Assembly

Maintenance
January 2019 6-7
Important
Remove all pressure from hydraulic systems before attempting any
service work on hydraulic components.
Hydraulic system must be bled after it has been serviced (if any portion
of the system has been opened to atmosphere) and also on initial
start-up or if spongy or irregular trip operation is occurring.
Opener Maintenance - Continued
Opener Body Assembly
Note: Openers should drop to the ground under their own weight, when the tractor
remote is placed into float position relieving oil pressure.
If it requires pressure to push an opener down to the ground during this
procedure, one or more of the pivot bolts are over tightened.
Check and adjust pivot bolts as required.
Item Part No. Description Qty
1 C64546 Cylinder - 1 3/4 Bore x 4 Stroke ........................................................................................ 1
2 D-5273 Lock Nut - 3/4 Unitorque ................................................................................................... 6
3 D-5278 Lock Nut - 5/16 Flanged .................................................................................................... 1
4 N31012 Carriage Bolt - 5/16 x 1 1/4 Lg .......................................................................................... 1
5 S62986 Q2 Bushing - 1 ID x 1 1/8 OD x 1 1/2 Lg Nominal size ..................................................... 6
6 S62987 Q2 Bushing - 1 ID x 1 1/8 OD x 1 Lg Nominal size ........................................................... 8
7 S62998 Mounting Bracket - (Includes Item 5 Qty of 2) ................................................................... 1
8 S64119 Opener Body ..................................................................................................................... 1
9 S64172 Bottom Link ....................................................................................................................... 1
10 S64580 Washer - 1 1/32 ID x 2 OD x 1/8 ....................................................................................... 6
11 S64672 Packer Arm ........................................................................................................................ 1
12 S66251 Shim - Depth Adjustment - 1/4 Thick ................................................................................. 1
13 S64759 Strap - Top Link.................................................................................................................. 1
14 S65009 Top Link ............................................................................................................................. 1
15 S65037 Pin - 1 Dia x 4 21/32 UL (Includes W21776 Roll Pin) ........................................................ 3
16 S65038 Pin - 1 Dia x 5 9/16 UL (Includes W21776 Roll Pin) .......................................................... 2
17 S65039 Pin - 1 Dia x 1 29/32 UL (Includes W21776 Roll Pin) ........................................................ 1
18 S65048 Cast Shankholder - (Includes Item 6 Qty of 2) .................................................................. 1
19 D-5498 Washer - 1.062 ID x 2 OD x 11 GA .................................................................................... 2
