Maintenance
January 2019 6-9
Important
Remove all pressure from hydraulic systems before attempting any service work on hydraulic
components.
Hydraulic system must be bled after it has been serviced (if any portion of the system
has been opened to atmosphere) and also on initial start-up or if spongy or irregular trip
operation is occurring.
Opener Maintenance - Continued
Opener Assembly
Item Part No. Description Qty
1 S65000 Cam Brace Bushing - 0.765 ID x 1-1/8 OD x 0.58 Lg ........................................................ 2
2 D-5558 Hex Bolt - 3/4 x 6 Lg.......................................................................................................... 1
3 D-5273 Lock Nut - 3/4 Unitorque ................................................................................................... 7
4 D-5274 Lock Nut - 1 Unitorque ...................................................................................................... 1
5 D12903 Hex Bolt - 1 x 7 Lg............................................................................................................. 1
6 D-5272 Lock Nut - 5/16 Unitorque ................................................................................................. 1
7 S66403 Hex Bolt - 1/2 x 4 1/2 Lg - GR.8 ........................................................................................ 1
8 S42294 Lynch Pin - 3/16 Dia x 1-3/8 Lg ......................................................................................... 1
9 S47110 Hex Nut - 1/2 Center Lock ................................................................................................. 3
10 S49260 Depth Cam - Cast ............................................................................................................. 1
11 S50246 Tapered Wheel Nut - 1/2-20UNF ....................................................................................... 5
12 S50247 Press-In Wheel Stud - 1/2 - 20UNF ................................................................................... 5
13 S64194 Otico Tire - 4 1/2 ................................................................................................................ 1
S64195 Otico Tire - 5 1/2 ................................................................................................................
14 S64673 Packer Arm ........................................................................................................................ 1
15 S64698 Bushing - 0.510 ID x 0.750 OD x 3.094 Lg ....................................................................... 1
16 S65061 Depth Pin - 1/2 Dia ............................................................................................................ 1
17 S65070 Hose Holder ...................................................................................................................... 1
18 S65121 Right Sideband Boot Kit - SHIELD CORE ........................................................................ 1
S65122 Left Sideband Boot Kit - SHIELD CORE
S65123 Paired Row Boot Kit - SHIELD CORE
* * * * * Single Shoot Boot Kit - SHIELD CORE
19 S66337 Cast Center Wedge - 3 wide ............................................................................................. 1
20 S66338 Cast Outer Wedge - 2 3/4 wide ......................................................................................... 2
21 S65650 Row Unit - Right (Includes items 1,2,3,7,8,9,10,11,12,14,15,16 and 25) ........................... 1
S65651 Row Unit - Left (Includes items 1,2,3,7,8,9,10,11,12,14,15,16 and 25) ..............................
22 S51466 Carriage Bolt - 5/16 x 2 Lg ................................................................................................ 1
23 S65851 Hose Holder Bracket - Cast Shankholder ......................................................................... 1
23A S68009 Hose Holder Bracket - Steel Shankholder
24 W-487 Hex Bolt - 1/2 x 1 3/4 Lg.................................................................................................... 2
24A S51464 Hex Bolt - 1/2 x 2 Lg - GR 8 (Hose Holder Replacement Bolt) ........................................ 1
25 S65821 Washer - 2 1/4 OD x 25/32 ID .......................................................................................... 1
26 S66245 Hose Holder - Opener ....................................................................................................... 1
26A S67170 Hose Holder - Opener - Low Profile - 4 per machine
27 S65852 Hose Holder Kit - Cast Shankholder - Contains Items 6, 9, 17, 22, 23 & 24A ................... 1
S68273 Hose Holder Kit - Steel Shankholder - Contains Items 6, 9, 17, 22, 23A & 24A
28 S66171 Openers Number Decal - 1 per machine
