7.29.17.2
Viewing the IP Information
When and where to use:
This feature displays the device name, IP address, and status of your radio.
NOTE: The device name of your radio is preprogrammed. Check with your dealer or system
administrator for more information.
Procedure:
1 Perform one of the following actions:
• Press the preprogrammed Info button.
• or to Info and press the Menu Select button directly below Info.
2
or to IP Info and press the Menu Select button directly below Sel.
The display shows the IP Info screen.
3 Perform one of the following actions:
• or to scroll through the various information.
• Press the Menu Select button directly below Back to return to the previous screen.
• Press to return to the Home screen.
7.29.17.3
Viewing the Control Assignments
When and where to use: This feature displays the programmable radio functions assigned to the
controls of your radio for the currently selected channel.
See Programmable Features on page 22 for more information on the various programmable features
of your radio.
Procedure:
1 Perform one of the following actions:
• Press the preprogrammed Info button.
• or to Info and press the Menu Select button directly below Info.
2
or to Control map and press the Menu Select button directly below Sel.
The display shows the Control Map screen.
3 Perform one of the following actions:
• or to scroll through the various information.
• Press the Menu Select button directly below Back to return to the previous screen.
• Press to return to the Home screen.
7.29.18
Front Panel Programming
You are able to customize certain feature parameters in Front Panel Programming (FPP) to enhance
the use of your radio.
The radio can be programmed in two ways:
• Front Panel Programming (FPP) using the front panel controls of the radio.
68012003048-GW
Chapter 7 : Advanced Features
122
