Icon Description
The radio is receiving and transmitting the broadband signal.
The ARS user logged on successfully with the broadband system.
The radio is receiving a broadband signal with the ARS user logged on.
The radio is transmitting a broadband signal with the ARS user logged on.
The radio is receiving and transmitting broadband signals with the ARS user
logged on.
Your radio is connected to a Wi-Fi
®
network. The number of bars represents
the signal strength of the Wi-Fi network.
On
The current channel is capable of supporting SmartConnect.
Inverted
The current channel is currently connected through the SmartConnect fea-
ture.
4.4
TMS Status Icons
This feature only supports Model 3.5 and Model 2.5.
Text Messaging Service (TMS) icons appear on the radio display when you send and receive text
messages.
Table 2: TMS Status Icons
Icon Description
The inbox is full.
The text message is sent.
The text message cannot be sent.
The selected text message in the inbox is not read.
The selected text message in the inbox is read.
The message has normal priority without a request for reply.
The Request Reply feature is toggled on before the message
is sent.
68012003048-GW
Chapter 4 : Status Indicators
31
