Icon Description
Y
Contains Zone 73, Zone 74, and Zone 75.
Top Display:
On
Secure operation.
Off
Clear operation.
Blinking
Receiving an encrypted voice call.
On
The radio is operating in an Advanced Encryption Standard (AES) secure
channel.
Off
The AES operation is cleared.
Blinking
The radio is receiving an AES-encrypted voice call.
On
The Global Position System (GPS) feature is enabled, and the signal is
available.
Blinking
The GPS feature is enabled, but no signal is available.
User Login Indicator (IP Packet Data)
On
The user is associated with the radio.
Blinking
The device registration or user registration with the server failed due to an
invalid username or pin.
Inverted
The user is logged on to the secured IP packet data.
Data activity is present on the radio.
Top Display:
The Bluetooth wireless technology is turned on and ready for connection.
Top Display:
Steady
Bluetooth is connected to the external Bluetooth device.
Blinking
Bluetooth device is disconnected.
Steady
The broadband system is available and connected.
