AP-7131 Access Point Product Reference Guide
2-14
The mounting tools (customer provided) and hardware required to install the AP-7131 on a ceiling
T-bar consists of:
• Safety wire (recommended and customer supplied)
• Security cable (and customer supplied)
To install the AP-7131 on a ceiling T-bar:
1. Motorola recommends you loop a safety wire—with a diameter of at least 1.01 mm (.04 in.),
but no more than 0.158 mm (.0625 in.) —through the tie post (above the AP-7131’s console
connector) and secure the loop.
2. If desired, install and attach a security cable to the AP-7131 lock port.
3. Attach the radio antennas to their correct connectors.
For more information on the antennas available to the AP-7131, see Antenna Options on
page 2-4.
4. Cable the AP-7131 using either the AP-7131 Power Injector solution or the AP-7131
approved power supply.
For Power Injector installations:
a. Connect a RJ-45 CAT 5 Ethernet cable between the network data supply (host) and the
Power Injector Data In connector.
b. Connect a RJ-45 CAT 5 Ethernet cable between the Power Injector Data & Power Out
connector and the AP-7131 GE1/POE port.
c. Ensure the cable length from the Ethernet source to the Power Injector and AP-7131 does
not exceed 100 meters (333 ft). The Power Injector has no On/Off power switch. The
Power Injector receives power as soon as AC power is applied. For more information on
using the Power Injector, see AP-7131 Power Injector System on page 2-7.
For standard 48-Volt Power Adapter (Part No. 50-14000-247R) and line cord installations:
a. Connect a RJ-45 CAT 5 Ethernet cable between the network data supply (host) and the
AP-7131 GE1/POE port.
b. Verify the power adapter is correctly rated according the country of operation.
c. Connect the power supply line cord to the power adapter.
CAUTION Do not supply power to the AP-7131 until the cabling of the unit is
complete.
!
