Motorola APX 3000

English
m
ASTRO
®
APX™ 3000
Digital Portable Radios
Quick Reference Card
RF ENERGY EXPOSURE AND PRODUCT SAFETY
GUIDE FOR PORTABLE TWO-WAY RADIOS
ATTENTION!
This radio is restricted to occupational use only to satisfy
FCC RF energy exposure requirements. Before using this
product, read the guide enclosed with your radio which contains
important operating instructions for safe usage and RF energy
awareness and control for compliance with applicable standards
and regulations.
Radio Controls
Radio On/Off
Channels and Volume
*Middle Side Button is programmable.
** Up and Down Arrow button default function is
to adjust volume.
Entering a Channel/Zone
Sending an Emergency Alarm
**Default emergency button press timer is set
to 1 second. This timer is programmable, see
page 36 in the user guide for details.
To exit emergency at any time, press and hold
the Emergency button.
Before using this product, read the operating instructions
for safe usage contained in the Product Safety and RF
Exposure booklet enclosed with your radio.
!
Caution
Top Button
____________
Up Arrow
Button**
____________
Antenna
Top Side Button
____________
Middle Side
Button*
(1)____________
(2)____________
Down Arrow
Button**
____________
On/Off Switch
IMPORANT!
You must connect a speaker microphone,
earpiece or headset to hear the audio indicators
and a GCAI DRSM to see the strings and icons
your radio displays.
• On – Push the On/Off Switch downwards. You
see a Green Dot.
• Off – Push the On/Off Switch upwards.
• Middle Side Button* – To toggle between
Volume, Channel or Zone mode.
Side
Connector
Cover
Battery
Connector
Transmit/
Receive LED
Battery
Bluetooth
Pairing
Spot
Bluetooth
LED
• Up Arrow Button** – To increase volume; to
toggle the channels or zones up.
• Down Arrow Button** – To decrease volume;
to toggle the channels or zones down.
1 Press the Middle Side Button to toggle to
channel/zone mode.
2 Up Arrow Button or Down Arrow Button to
change the channel/zone.
3 Adjust volume, if necessary.
4 Press the PTT button to transmit; release to
receive.
1 Press and release the Emergency button**.
2 When acknowledgment is received, you hear
four beeps; alarm ends; and radio exits
emergency.
*PMLN6407A*
PMLN6407A
