Motorola ASTRO XTL 2500

ASTRO XTL 2500 Digital Mobile Radio with M5 Control Head 13
Multiple Control Head Features
Overview
The XTL 2500 Digital Mobile Radio supports radio configurations of
up to two M5 control heads. You may use the CAN cable to connect
the multiple control heads in any permutation. For example: Daisy
chain control head to another control head or attaching two control
heads to a transceiver. The control heads in a multiple control head
configuration may mix and match different types of microphones
(e.g., palm microphone and keypad microphone).
The Multiple Control Head feature for the XTL 2500 radio consists of
2 modes:
• All Active mode
• One Active mode
Note: The default Multiple Control Head mode can be changed
by a qualified radio technician using the radio’s
programming software.
XTL 2500 900 MHz does not support Multi Control Head
features.
If you try to plug-in the handset after
the radio has been turned on, the
radio may
fail to detect the
connection.
CAUTION
!
