MOTOROLA M68000 8-/16-/32-BIT MICROPROCESSORS USER'S MANUAL 10-21
CLK
47
33
35
34
37A
47
47
46
37
57
16
57A
BR
BG
BGACK
AS
DS
VMA
R/W
FC2-FC0
A19-A0
D7-D0
NOTE: Waveform measurements for all inputs and outputs are specified at: logic high 2.0 V, logic low = 0.8 V.
1 MC68008 52-Pin Version Only.
7
1
Figure 10-10. Bus Arbitration Timing — Active Bus Case
(Applies To All Processors Except The MC68EC000)
