10-22 M68000 8-/16-/32-BIT MICROPROCESSORS USER'S MANUAL MOTOROLA
CLK
33
35
37
57A
BR
BG
BGACK
AS
DS
VMA
R/W
FC2-FC0
A19-A0
D7-D0
47
3939
46
37
46
38
36
58
NOTES: Waveform measurements for all inputs and outputs are specified at: logic high 2.0 V, logic low = 0.8 V.
1. MC68008 52-Pin Version only.
1
Figure 10-11. Bus Arbitration Timing — Multiple Bus Request
(Applies To All Processors Except The MC68EC000)
