11-8 M68000 8-/16-/32-BIT MICROPROCESSORS USER'S MANUAL MOTOROLA
64
32
1
B
F
G
D
C
N
K
M
L
J
L SUFFIX
746-03
NOTES:
1. DIMENSION -A- IS DATUM.
2. POSTIONAL TOLERANCE FOR LEADS:
4. DIMENSION "L" TO CENTER OF LEADS
WHEN FORMED PARALLEL.
3. -T- IS SEATING PLANE
5. DIMENSIONING AND TOLERANCING PER
ANSI Y14.5m, 1982.
DIM
MILLIMETERS INCHES
MIN MAX
MIN MAX
A
B
C
D
F
G
J
K
L
M
N
60.36 61.56 2.376 2.424
14.64 15.34 0.576 0.604
3.05 4.32
0.120 0.160
3.81 0.533
0.015 0.021
.762
1.397
0.030 0.055
2.54 BSC 0.100 BSC
0.204 0.330
0.008 0.013
2.54 4.19
0.100 0.165
0
10 0 10
1.016
1.524
0.040 0.060
33
A
T
M
0.25 (0.010) T A
M
15.24 BSC 0.600 BSC
Figure 11-7. Case 740-03—L Suffix
