MOTOROLA M68000 8-/16-/32-BIT MICROPROCESSORS USER'S MANUAL 11-9
48
24
1
A
B
FGD
C
N
K
M
L
J
P SUFFIX
767-02
H
NOTES:
1. -R- IS END OF PACKAGE DATUM PLANE
-T- IS BOTH A DATUM AND SEATING PLANE
2. POSITIONAL TOLERANCE FOR LEADS 1 AND
48.
3. DIMENSION "A" AND "B" DOES NOT INCLUDE MOLD FLASH,
MAXIMUM MOLD FLASH 0.25 (0.010).
4. DIMENSION "L" IS TO CENTER OF LEADS WHEN FORMED
PARALLEL.
5. DIMENSIONING AND TOLERANCING PER ANSI Y14.5, 1982.
6. CONTROLLING DIMENSION: INCH.
DIM
MILLIMETERS INCHES
MIN MAX MIN MAX
A
B
C
D
F
G
H
J
K
L
M
N
61.34 62.10 2.415 2.445
13.72 14.22 0.540 0.560
3.94 5.08 0.155 0.200
0.36 0.55 0.014 0.022
1.02 1.52 0.040 0.060
2.54 BSC 0.100 BSC
0.20
0.38 0.008 0.015
2.92
3.81 0.115 0.135
15.24 BSC 0.600 BSC
015015
0.51 1.02 0.020 0.040
1.79 BSC
0.070 BSC
25
R
T
M
0.51 (0.020) T B R
POSITIONAL TOLERANCE FOR LEAD
PATTERN;
M
0.25 (0.020) T B
Figure 11-8. Case 767-02—P Suffix
